Transparent Level Indicator Transmitter
Transparent Level Indicator Transmitter
roduct Code: TTI2000
Transparent Level Gauges are Designed specially to meet the most critical requirements of Petrochemical, Fertilizer, Pharmaceutical & Chemical Industries Involving Inflammable Toxic, High Pressure, High temperature liquids. Permits observations of level colour and clarity of liquid through pair of heavy duty glasses on either side of Liquid chamber. The Liquid enters the chamber on either side of which are a pair of heavy duty glasses, which permits observations of level, colour and clarity of the Liquid.
Specification
| Application | : | Liquids |
| Liquid Chamber (Wetted Part) | : | MS/CS/ASTM A105/SS304/SS316/PP Other Materials on request |
| Cover Plate (Non Wetted Part) | : | MS/CS/ASTM A105/SS304/SS316/PP Other Materials on request |
| Design Temperature | : | Upto 230°C |
| Design Pressure | : | Up to 40 Kg/cm² |
| C/C Distance | Upto 6000 mm | |
| Connection | : | Flanged to ASA/BS/DIN/Socket Weld/Butt Weld |
Transparent Level Indicator Transmitter
Transparent Level Indicator With 2 Nos Isolation Valve And 1 No. Drain Valve
Product Code TTI2000-2IV-1DV
Transparent Level Indicator Without Isolation and Drain Valve
Product Code TTI2000-NIVD
Transparent Level Indicator With Vertical Connection
Product Code TTI2000-VF
Transparent Level Indicator With Spring Loaded Push Valve & Drain Valve
Product Code TTI2000-SPRDV
Transparent Level Indicator With Frost Free Arrangement
Product Code TTI2000-VFFA
Transparent Level Indicator With High & Low Level Switch
Product Code TTI2000-HLS
Transparent Level Indicator With Steam Jacket
Product Code TTI2000-SJ
Tubular Level Indicator without Isolation Valve and With Drain Valve
Product Code TLG 4400-DV
